Aeromotive Fuel System Fuel Filters and Components 12304

SKU: 12304

$197.63

Aeromotive Fuel System Fuel Filters and Components 12304

O-Ring Boss-10 Ports
Aeromotive Fuel System Fuel Filters and Components 12304

Limited 1 Year Warranty
Aeromotive Fuel System Fuel Filters and Components 12304

CNC Machined From 6061-T6 Aircraft Aluminum
Aeromotive Fuel System Fuel Filters and Components 12304

High Flow, 100 Micron Stainless Steel (Coarse) Cleanable Element
Aeromotive Fuel System Fuel Filters and Components 12304

Flows 2,000 Pounds Per Hour With A Pressure Drop Of Less Than 1 PSI

Verified U.S. Supplier

Fitment Data Included

30-Day Returns
In stock 40

Prop 65 Warning

WARNING: Cancer and reproductive harm - www.P65Warnings.ca.gov

Emissions & Compliance

Emissions Compliance Exempt
  • Visa
  • Mastercard
  • Diners Club
  • PayPal
  • American Express
Aeromotive Fuel System Fuel Filters and Components 12304

$197.63

$197.63

Complete Assembly

Type

In-Line

Location

Gasoline/ Alcohol

Fuel Type

Product Description

An inexpensive insurance policy to protect your investment. Proper filtration is key to fuel system performance. Engineered filter solutions are required to achieve protection with minimum restriction. For 200 to 3,000 plus Horsepower applications, our filter assemblies offer unmatched flow, ease of installation and maintenance, along with the impeccable machining and finish you’ve come to expect from all Aeromotive components.

More Features
  • Fittings Available To Adapt These Filters To AN -10, -08 And -06 Line Sizes
  • All Filter Assemblies Feature An O-Ring For Positive Sealing In High Pressure Applications
  • Bright Dip Red Anodized Finish For A Corrosion Resistant, Show Car Quality Appearance

Specifications

Type
Complete Assembly
Location
In-Line
Fuel Type
Gasoline/ Alcohol
Inlet Connection Size
5/8 Inch (-10 AN)
Inlet Connection Type
Female Threads
Outlet Connection Size
5/8 Inch (-10 AN)
Outlet Connection Type
Female Threads
Diameter (IN)
2 Inch
Length (IN)
Not Applicable
Width (IN)
Not Applicable
Height (IN)
5-1/2 Inch
Micron Rating
100 Micron
Element Material
Stainless Steel
Finish
Anodized
Color
Red
Material
Aluminum
With Gasket
Yes
With Hose
No
With Mounting Hardware
No
Estimated Install Time (Hours)
0.5
