Warn 43 Feet Winch 94000

SKU: 94000

$699.99

Warn 43 Feet Winch 94000

Limited 1 Year Warranty
Warn 43 Feet Winch 94000

Automatic Disc Brake Holds Full Rated Load
Warn 43 Feet Winch 94000

Powerful Series-Wound DC Motor With Robust Sealing
Warn 43 Feet Winch 94000

Large-Frame Design With A Cast Aluminum Drum Provides Plenty Of Wire Rope Capacity
Warn 43 Feet Winch 94000

Proven 3-Stage All-Metal Gear Train With Permanent Grease Lubrication For Years Of Trouble-Free Service
In stock 31

Prop 65 Warning

WARNING: Cancer and reproductive harm - www.P65Warnings.ca.gov

Emissions & Compliance

Emissions Compliance Exempt
  • Visa
  • Mastercard
  • Diners Club
  • PayPal
  • American Express
Warn 43 Feet Winch 94000

$699.99

$699.99

43 Feet

Line Length

4000 Pound

Winch Rating

Electric

Operation Type

Product Description

The hoist combines a powerful series wound DC motor with robust sealing and our proven 3-stage all metal geartrain. Permanent grease lubrication means years of trouble free service. All WARN hoists incorporate an automatic mechanical brake that holds full rated load. The durable powder coated finish stands up to the elements and looks great. The hoist is built on WARN's robust large frame design with a cast aluminum drum to provide plenty of wire rope capacity.

Specifications

Winch Rating
4000 Pound
Recommended Use
Trailer
Operation Type
Electric
Mount Type
Fixed Mount
Voltage
12 Volt
Free Spooling
No
Line Length (FT)
43 Feet
Line Material
Steel
Remote Type
Wired
Universality
Fully Universal
Mounting Pattern Size
2-1/2 Inch Length X 3 Inch Width
Brake Type
Dynamic And Mechanical
Max Amp Draw
240 Amp Draw At 4000 Pound
Gear Reduction Ratio
176
Includes Mounting Hardware
Yes
Thermal Shutoff
No
Color
Black
Motor Horsepower
1.9 Horsepower
Fairlead Type
Roller
Line Speed At Max Pull
6.9 Feet Per Minute At 4000 Pound
Electrical Control Type
Solenoid
Motor Type
Permanent Magnet
Drive Gear Type
Planetary
Line Diameter (IN)
7/32 Inch
Mounting Hole Quantity
3
Estimated Install Time (Hours)
2

Installation & Documents



4000 Utility Winch Service Manual.pdf
International Warranty.pdf
