MSD Ignition Distributor, For Use With Chevy V8 Engines, Red Cap With HEI/Male Posts - 85551

SKU: 85551

$399.95

MSD Ignition Distributor, For Use With Chevy V8 Engines, Red Cap With HEI/Male Posts - 85551

Easy to adjust mechanical advance with supplied springs and stop bushings.
MSD Ignition Distributor, For Use With Chevy V8 Engines, Red Cap With HEI/Male Posts - 85551

CNC machined billet aluminum housing and billet aluminum base.
MSD Ignition Distributor, For Use With Chevy V8 Engines, Red Cap With HEI/Male Posts - 85551

Advance weight pins are staked and TIG welded to the plate, nylon pads ensure smooth operation of the advance weights.
MSD Ignition Distributor, For Use With Chevy V8 Engines, Red Cap With HEI/Male Posts - 85551

Maintenance free magnetic pickup and precision reluctor create stable trigger signals throughout the RPM range.
MSD Ignition Distributor, For Use With Chevy V8 Engines, Red Cap With HEI/Male Posts - 85551

Mechanical advance assembly can be locked out for crank trigger systems.
61 In Stock - Ships in 1-3 days

Shipping & Returns

Shipping

Most in-stock products ship within 1-3 business days. Your available shipping method and final shipping cost will be shown at checkout. Qualifying standard-shipping orders of $150 or more ship free, while larger items may require oversized or freight delivery.

For more information, view our Shipping Policy.

Returns

Changed your mind? Most products can be returned within 30 days of delivery as long as they are unused, uninstalled, and in their original condition.

Contact us to start a return, and we’ll guide you through the next steps.

For complete details, view our Returns & Refunds Policy.

Warranty

Available warranty coverage is provided by the manufacturer and varies by brand and product. Modridge assists customers with eligible warranty claims and helps coordinate the review process with the manufacturer.

Contact us before returning, repairing, modifying, or discarding a product that may be defective. Order information, photographs, installation details, and diagnostic information may be required.

For coverage details and claim instructions, review our Warranty Policy.

Prop 65 Warning

WARNING: Cancer and reproductive harm - www.P65Warnings.ca.gov
  • Visa
  • Mastercard
  • Diners Club
  • PayPal
  • American Express
MSD Ignition Distributor, For Use With Chevy V8 Engines, Red Cap With HEI/Male Posts - 85551

$399.95

$399.95

Magnetic Trigger

Spark Distribution Type

Iron Gear

Drive Gear Type

HEI/ Male Posts

Cap Type

Product Description

This is our most popular performance distributor! The housing is machined from a billet of 6061-T6 aluminum on a state-of-the-art CNC machine producing exact tolerances. For high RPM stability, a 0.500 Inch steel shaft is supported by a sealed ball bearing and a long sintered bushing. This shaft also receives a QPQ coating for friction reduction and resistance to corrosion. A precision machined reluctor is attached to the shaft which triggers the magnetic pickup mounted in the housing.

This high output magnetic pickup is the most accurate way to trigger your ignition. Plus, with no moving parts to wear or adjust, the pick up is maintenance free! Just above the pick up is MSD's adjustable mechanical advance assembly. Different springs and stop bushings are supplied so you can tune an advance curve to match your application.


Additional Details

  • Polished steel shaft is QPQ coated and guided by a sealed ball bearing, advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction.
  • Limited 1 year warranty.
  • For use with chevy V8 engines.
  • Without ignition control module.
  • With iron gear.
  • Red cap with HEI/male posts.

Specifications

Condition
New
Finish
Polished Shaft
Recommended Use
Street/ Strip/ Track/ Off-Road
Spark Advance Type
Mechanical Advance
Spark Distribution Type
Magnetic Trigger
Drive Gear Type
Iron Gear
With Ignition Module
No
With Tach Drive
No
Includes Cap And Rotor
Yes
Cap Color
Red
Cap Type
HEI/ Male Posts
Coil In Cap
No
Additional Specification
Pro-Billet

Installation & Documents


85551.pdf
msd_brand_warranties.pdf
