Maretron Marine Network Port Expander, Blue-Gray Nylon Housing, 250 V Operating Voltage, 4 Ampere Operating Current - CM-CF-4

SKU: CM-CF-4

$101.99

Maretron Marine Network Port Expander, Blue-Gray Nylon Housing, 250 V Operating Voltage, 4 Ampere Operating Current - CM-CF-4

Multiport boxes allow several drop cables to be consolidated.
Maretron Marine Network Port Expander, Blue-Gray Nylon Housing, 250 V Operating Voltage, 4 Ampere Operating Current - CM-CF-4

Ideal for consolidating many connections; for example behind dashboards.
Maretron Marine Network Port Expander, Blue-Gray Nylon Housing, 250 V Operating Voltage, 4 Ampere Operating Current - CM-CF-4

Requires the purchase of an additional double-ended cordset for connection back to the trunk.
Maretron Marine Network Port Expander, Blue-Gray Nylon Housing, 250 V Operating Voltage, 4 Ampere Operating Current - CM-CF-4

250 V operating voltage.
Maretron Marine Network Port Expander, Blue-Gray Nylon Housing, 250 V Operating Voltage, 4 Ampere Operating Current - CM-CF-4

Includes micro-mid male homerun / micro-mid female drops.
25 In Stock - Ships in 1-3 days

Shipping & Returns

Shipping

Most in-stock products ship within 1-3 business days. Your available shipping method and final shipping cost will be shown at checkout. Qualifying standard-shipping orders of $150 or more ship free, while larger items may require oversized or freight delivery.

For more information, view our Shipping Policy.

Returns

Changed your mind? Most products can be returned within 30 days of delivery as long as they are unused, uninstalled, and in their original condition.

Contact us to start a return, and we’ll guide you through the next steps.

For complete details, view our Returns & Refunds Policy.

Warranty

Available warranty coverage is provided by the manufacturer and varies by brand and product. Modridge assists customers with eligible warranty claims and helps coordinate the review process with the manufacturer.

Contact us before returning, repairing, modifying, or discarding a product that may be defective. Order information, photographs, installation details, and diagnostic information may be required.

For coverage details and claim instructions, review our Warranty Policy.
  • Visa
  • Mastercard
  • Diners Club
  • PayPal
  • American Express
Maretron Marine Network Port Expander, Blue-Gray Nylon Housing, 250 V Operating Voltage, 4 Ampere Operating Current - CM-CF-4

$101.99

$101.99

Product Description

Multiport boxes allow several drop cables to be consolidated and connected back to the trunk, which eliminates the need to have numerous tees connected near a single point. Multiport boxes connect back to the trunk through a double-ended cordset and Tee. Used to consolidated and connected cables back to the trunk.


Additional Details

  • NMEA 2000 approved.
  • Blue-gray nylon housing.
  • IP67 waterproof (when receptacles are covered).
  • -22 degree fahrenheit to 176 degree fahrenheit operating temperature.
  • Approvals: NMEA 2000 approved/ IEC 61162-3.

Specifications

Number Of Ports
5
Includes
With Cap

Installation & Documents


Micro Term Feed thru Multi Datasheet.pdf
