Blue Sea Circuit Breaker, 187 Series, 60 amp/48 V DC, 5/16 in-18 Stud Terminal - 7140-BSS
Blue Sea Circuit Breaker, 187 Series, 60 amp/48 V DC, 5/16 in-18 Stud Terminal - 7140-BSS
Blue Sea Circuit Breaker, 187 Series, 60 amp/48 V DC, 5/16 in-18 Stud Terminal - 7140-BSS

Authorized Dealer

Blue Sea Circuit Breaker, 187 Series, 60 amp/48 V DC, 5/16 in-18 Stud Terminal - 7140-BSS

SKU: 7140-BSS

$109.99

Blue Sea Circuit Breaker, 187 Series, 60 amp/48 V DC, 5/16 in-18 Stud Terminal - 7140-BSS

Combines switching and circuit protection into a single device.
Blue Sea Circuit Breaker, 187 Series, 60 amp/48 V DC, 5/16 in-18 Stud Terminal - 7140-BSS

Ignition protected - safe for installation aboard gasoline powered boats.
Blue Sea Circuit Breaker, 187 Series, 60 amp/48 V DC, 5/16 in-18 Stud Terminal - 7140-BSS

Large clearance around terminal studs accepts heavy gauge wire lugs.
Blue Sea Circuit Breaker, 187 Series, 60 amp/48 V DC, 5/16 in-18 Stud Terminal - 7140-BSS

Robust terminals provide high torque connections.
Blue Sea Circuit Breaker, 187 Series, 60 amp/48 V DC, 5/16 in-18 Stud Terminal - 7140-BSS

Visible yellow reset lever shows open condition.
37 In Stock - Ships in 1-3 days

Shipping & Returns

Shipping

Most in-stock products ship within 1-3 business days. Your available shipping method and final shipping cost will be shown at checkout. Qualifying standard-shipping orders of $150 or more ship free, while larger items may require oversized or freight delivery.

For more information, view our Shipping Policy.

Returns

Changed your mind? Most products can be returned within 30 days of delivery as long as they are unused, uninstalled, and in their original condition.

Contact us to start a return, and we’ll guide you through the next steps.

For complete details, view our Returns & Refunds Policy.

Warranty

Available warranty coverage is provided by the manufacturer and varies by brand and product. Modridge assists customers with eligible warranty claims and helps coordinate the review process with the manufacturer.

Contact us before returning, repairing, modifying, or discarding a product that may be defective. Order information, photographs, installation details, and diagnostic information may be required.

For coverage details and claim instructions, review our Warranty Policy.

Prop 65 Warning

WARNING: Cancer and reproductive harm - www.P65Warnings.ca.gov
  • Visa
  • Mastercard
  • Diners Club
  • PayPal
  • American Express
Blue Sea Circuit Breaker, 187 Series, 60 amp/48 V DC, 5/16 in-18 Stud Terminal - 7140-BSS

$109.99

$109.99

60 A

Current Rating

48 V

Voltage Rating

Screw

Terminal Connection

Product Description

Circuit breakers protect the wire in electrical circuits. Blue Sea Systems broad selection of magnetic and thermal circuit breakers include a vast selection of main and branch circuit protection devices. Their robust design makes them ideal for marine and vehicle AC and DC electrical systems. Thermal circuit breakers provides heavy duty circuit protection for 25 To 200 Ampere loads when switching and circuit protection are both required.


Additional Details

  • Waterproof. clear, single lever operation.
  • Meets SAE J1171 external ignition protection requirements.
  • Trip free design cannot be held "on" during fault current condition.
  • Large lever with vertical or horizontal orientation provides indication of trip status; recessed mounting holes for clean appearance.

Specifications

Ampere Rating
60 Amp
Voltage Rating
48 Volt
Reset Type
Manual
Terminal Connection
Screw
Type
Thermal
Number of Poles
2
Quantity
Single
Estimated Install Time (Hours)
0.25
Additional Specification
Surface Mount
Additional Specification
Thermal Type
Additional Specification
Switchable/Manual Reset
