Bilstein Shock Absorber, B8 5100 Series, Extended Height 18.66 in/Compressed Height 13.86 in - 24-249928
Bilstein Shock Absorber, B8 5100 Series, Extended Height 18.66 in/Compressed Height 13.86 in - 24-249928
Bilstein Shock Absorber, B8 5100 Series, Extended Height 18.66 in/Compressed Height 13.86 in - 24-249928

Bilstein

Authorized Dealer

Bilstein Shock Absorber, B8 5100 Series, Extended Height 18.66 in/Compressed Height 13.86 in - 24-249928

SKU: 24-249928

$176.00

Bilstein Shock Absorber, B8 5100 Series, Extended Height 18.66 in/Compressed Height 13.86 in - 24-249928

46 mm monotube design ensures consistent, fade-free performance in all conditions.
Bilstein Shock Absorber, B8 5100 Series, Extended Height 18.66 in/Compressed Height 13.86 in - 24-249928

Utilizes vehicle's stock front coil springs and OEM mounting hardware.
Bilstein Shock Absorber, B8 5100 Series, Extended Height 18.66 in/Compressed Height 13.86 in - 24-249928

Increases suspension travel.
Bilstein Shock Absorber, B8 5100 Series, Extended Height 18.66 in/Compressed Height 13.86 in - 24-249928

Extended height 18.66 in / compressed height 13.86 in.
Bilstein Shock Absorber, B8 5100 Series, Extended Height 18.66 in/Compressed Height 13.86 in - 24-249928

Includes shock boots.
101 In Stock - Ships in 1-3 days

Shipping & Returns

Shipping

Most in-stock products ship within 1-3 business days. Your available shipping method and final shipping cost will be shown at checkout. Qualifying standard-shipping orders of $150 or more ship free, while larger items may require oversized or freight delivery.

For more information, view our Shipping Policy.

Returns

Changed your mind? Most products can be returned within 30 days of delivery as long as they are unused, uninstalled, and in their original condition.

Contact us to start a return, and we’ll guide you through the next steps.

For complete details, view our Returns & Refunds Policy.

Warranty

Available warranty coverage is provided by the manufacturer and varies by brand and product. Modridge assists customers with eligible warranty claims and helps coordinate the review process with the manufacturer.

Contact us before returning, repairing, modifying, or discarding a product that may be defective. Order information, photographs, installation details, and diagnostic information may be required.

For coverage details and claim instructions, review our Warranty Policy.

Prop 65 Warning

WARNING: Cancer and reproductive harm - www.P65Warnings.ca.gov
  • Visa
  • Mastercard
  • Diners Club
  • PayPal
  • American Express
Bilstein Shock Absorber, B8 5100 Series, Extended Height 18.66 in/Compressed Height 13.86 in - 24-249928

$176.00

$176.00

Eyelet

Upper Mount

Cross Pin

Lower Mount

Steel

Rod Material

Product Description

Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0 to 3 Inch of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46 Millimeter digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling.

Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.


Additional Details

  • 46 millimeter monotube design ensures consistent, fade-free performance in all conditions.
  • Adjustable spring perch for vehicle lift up to 2-3/4 inch, depending on application.
  • Patented digressive valving instantly reacts to changing surface conditions.
  • Extremely affordable and practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology.
  • Made in USA.
  • Limited lifetime warranty.
  • B8 5100 series.
  • Nitrogen gas charged.
  • Non adjustable valving.
  • Extended height 18.66 inches/ compressed height 13.86 inches.
  • With shock boots.

Specifications

Type
Nitrogen Gas Charged
With Coil Spring
No
Extended Length (IN)
18.66 Inch
Compressed Length (IN)
13.86 Inch
Upper Mounting Style
Eyelet
Lower Mounting Style
Cross Pin
Adjustable Valving
Yes
Quantity
Single
Universality
Vehicle Specific
Internal Design
Monotube
Body Color
Silver
Rod Diameter (IN)
1/2 Inch
Valving Type
Non Adjustable Valving
Rod Material
Steel
Body Material
Steel
With Reservoir
No
Includes Dust Shield
Yes
Includes Hardware
Yes
Includes Boot
Yes
Estimated Install Time (Hours)
0.5
Finish
Zinc Plated

Fitment / Application

1996-1997 Toyota Tacoma Rear Wheel Drive
1996-1997 Toyota Tacoma Four Wheel Drive
1998-2000 Toyota Tacoma SR5; Four Wheel Drive
1998-2000 Toyota Tacoma Pre Runner
1998-2000 Toyota Tacoma Limited
1999-2000 Toyota Tacoma SR5; Rear Wheel Drive
2001-2004 Toyota Tacoma Pre Runner; Xtra Cab (Extended)
2001-2004 Toyota Tacoma S-Runner
2001-2004 Toyota Tacoma Pre Runner; Double Cab (Crew)
2001-2004 Toyota Tacoma Pre Runner; Standard Cab
2004 Toyota Tacoma Base; Four Wheel Drive; Standard Cab
2004 Toyota Tacoma Base; Four Wheel Drive; Xtra Cab (Extended)
2004 Toyota Tacoma Base; Four Wheel Drive; Double Cab (Crew)
2004 Toyota Tacoma Base; Rear Wheel Drive; Standard Cab
2004 Toyota Tacoma Base; Rear Wheel Drive; Xtra Cab (Extended)
2004 Toyota Tacoma Base; Rear Wheel Drive; Double Cab (Crew)

Installation & Documents


B8_5100_RHA_Flyer.pdf
E4-WM5-Y489A00.pdf
warranty_all_v4.2.pdf
