Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327
Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327
Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327
Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327
Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327
Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327

Authorized Dealer

Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327

SKU: E70327

$524.99

Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327

Analog needle display reports relative wind angle from 000 degree to 180 degree.
Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327

Seatalkng, NMEA2000 and seatalk network compatible.
Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327

Colorized port and starboard segments call out close-hauled wind angles.
Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327

High contrast LCD for wind speed, beaufort, max wind, VMG, and tack angle reporting.
Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327

Red backlighting enhances night visibility.
67 In Stock - Ships in 1-3 days

Shipping & Returns

Shipping

Most in-stock products ship within 1-3 business days. Your available shipping method and final shipping cost will be shown at checkout. Qualifying standard-shipping orders of $150 or more ship free, while larger items may require oversized or freight delivery.

For more information, view our Shipping Policy.

Returns

Changed your mind? Most products can be returned within 30 days of delivery as long as they are unused, uninstalled, and in their original condition.

Contact us to start a return, and we’ll guide you through the next steps.

For complete details, view our Returns & Refunds Policy.

Warranty

Available warranty coverage is provided by the manufacturer and varies by brand and product. Modridge assists customers with eligible warranty claims and helps coordinate the review process with the manufacturer.

Contact us before returning, repairing, modifying, or discarding a product that may be defective. Order information, photographs, installation details, and diagnostic information may be required.

For coverage details and claim instructions, review our Warranty Policy.
  • Visa
  • Mastercard
  • Diners Club
  • PayPal
  • American Express
Raymarine Sailboat Instrument Kit, i70s, 4 in LCD Display, 1.7 Watt Power Consumption - E70327

$524.99

$524.99

-13-131 °F

Operating Temperature

12 V

Voltage Rating

1.7 W

Power Usage

Product Description

The i60 Wind instrument display calculates both true and apparent wind speed and angle. Wind angle is presented on an easy-to-understand analog needle gauge, while wind speed is reported on its high-contrast LCD readout. The i60 Wind instrument provides critical information for sailing vessels and is also right at home onboard well-equipped cruising and fishing powerboats. The i60 Wind instrument is engineered for easy viewing, by day or night.

Its high-contrast LCD and red backlighting combine to deliver superior visibility under all conditions. i60 instruments also support local and group dimming control. This makes it easy to adjust the brightness of multiple Raymarine products all at once. Simple push button controls provide easy access to all its data displays. i60 series instruments are the perfect combination of powerful performance, easy operation and rugged reliability. All i60 instruments are designed to fully integrate with Raymarine's autopilots and other navigation equipment.

Each i60 instrument can be configured as a Master display, hosting its own transducer, or as a Repeater display, showing information from another source on the network. i60 instruments are SeaTalkng network-ready and can be easily adapted to connect to NMEA2000 or older SeaTalk networks.


Additional Details

  • Built-in wind transducer interface for traditional or rotavecta masthead units.
  • Compact footprint.
  • Low power consumption.
  • Surface mount or optional trunnion mount kit.
  • Limited 2 year warranty.
  • Provides analogue/ digital/ graphical displays of depth/ speed/ wind.
  • 1.7 watt power consumption.
  • IPX6/ IPX7 waterproof.
  • 320 x 240 pixels resolution.
  • -13 to 131 degree fahrenheit operating temperature.
  • With sun cover/ alternative gunmetal bezel/ 15.7 inch SeaTalkNG spur cable/ panel seal gasket/ cable suppression ferrite/ 4 mounting screws.
  • Europe 2004/108/EC, australia and new zealand c-tick, compliance level 2 standards.
  • Boat instrument display only.

Specifications

Mounting Style
Surface Mount
Display Type
LCD
With Transducer
No
Operational Temperature Range
-13 To 131 Degree Fahrenheit
Voltage Rating
12 Volt
Power Usage
1.7 Watt
Boat Speed
No
Course Information
No
Multi Language
No
Race Timer
No
Time
No
Water Current
No
Water Depth
No
Water Temperature
No
Wind Direction
No
Wind Speed
No
Wind Sensor Cable Length
Without Cable
Wind Instrument Display Size
4.33 Inch Width X 4.53 Inch Height X 1.17 Inch Depth
NMEA 2000 Certified
Yes
Waterproof Rating
IPX7 Waterproof
Includes
With Sun Cover/ Alternative Gunmetal Bezel/ 15.7 Inch SeaTalkNG Spur Cable/ Panel Seal Gasket
Electrical Rating
12 Volt DC
Additional Specification
Keypad Interface
